Electrical safety under indian electricity rules 1956

Rule 28: Voltage Level Definitions

Understanding the designated voltage levels is fundamental in electrical infrastructure. Rule 28 outlines the specific definitions, ensuring clarity and uniformity in electrical systems. According to this rule –

• Low Voltage – Does not exceeding 250 V
• Medium Voltage – Does not exceeding 650 V
• High Voltage – Does not exceeding 33 kV
• Extra High Voltage – Exceeding 33 kV

Rule 30: Service Lines & Apparatus on Consumer Premises

This rule delineates the guidelines regarding the installation of service lines and apparatus on consumer premises, emphasizing safety and efficiency. This rule defines that all the electrical wires, Electrical Devices, Accessories, and Power Supply lines must be kept in safe conditions and should be able to supply energy when they are free from any type of danger.

Rule 31: Cut-out on Consumer’s Premises

The installation of cut-outs on consumer premises is crucial for safeguarding against overloads or faults. Rule 31 highlights the importance of this component in preventing electrical mishaps. The supplier should provide a cutout in each conductor of every service lone other than an earthed or neutral conductor. And also every electrical conductor shall be protected by the cutout also by its owner.

Rule 46 & Rule 47: Inspection and Testing

Periodical inspection and testing of consumer installations (Rule 46) along with the specific testing procedures (Rule 47) are imperative measures to ensure ongoing safety and compliance. Proper testing and inspection of all electrical installation by a licensed inspector is mandatory at a time intervals. The inspection should be done at least every 5 years.

Rule 54 & Rule 55: Declared Voltage and Frequency

The declared voltage and frequency of supply to consumers are defined under Rules 54 and 55, maintaining consistency and reliability in power distribution. According to this rule 55, the voltage variation should not more than 6% and the frequency variation, according to the rule 55 should not more than 3%.

Rule 56: Sealing of Meters & Cut-Outs

Sealing meters and cut-outs is a protective measure to prevent tampering or unauthorized access, ensuring fair consumption measurement. This rule defines that all electric supply lines and apparatus must have proper rating of power, insulation, and fault current rating and also have mechanical strength.

Rule 77 & Rule 79: Clearances and Safety

Rules 77: This guideline outlines the minimum vertical space that electrical cables must have above ground. Maintaining a safe distance between the conductors and the ground to avoid inadvertent contact, lowers the possibility of electrical risks and guarantees the security of both staff and the general public.

Rule 79: The necessary horizontal space between electrical cables is specified in Rule 79. It places a strong emphasis on keeping a safe distance between wires in order to avoid any possible electrical failures or short circuits caused by contact between them. The purpose of this regulation is to protect the electrical system’s dependability and reduce the possibility of electrical arcing.

Rule 87 & Rule 88: Crossings and Guarding

Rule 87: When electrical lines approach or cross one another, this regulation provides rules. It outlines the steps that must be taken to guarantee security and avert any risks that might result from these crossings. The goal of the regulation is to reduce the possibility of accidents, short circuits, and interference caused by nearby or intersecting electrical lines.
